Overview
Product Features
- Pump type Electrical submersible One-phase and Three-phase
- Classification IP 68
- Max submersion 20m
- Cable 20m SUBCAB: 1-ph: 3G1.5mm2 3-ph: 4G1.5mm2
- Discharge connection Hose, ISO-G or NPT
- Limitations ph 5-8
- Max liquid temp 40°C
Product code 8101.160 and 8101.172;
The Minex pump is the smallest model in the drainage range, but it shares all important features and benefits with the larger models, resulting in the lowest cost per cubic meter pumped. The drainage range of pumps drain water, not your wallet! The revolutionary hydraulic design ensures high wear resistence and dramatically reduces performance drop due to long time wear. The Minex pump is available in two configurations;
Minex 1-phase (8101.160)
Minex 3-phase (8101.172)
The Minex pump is available in two configurations;
Minex 1-phase (8101.160)
Minex 3-phase (8101.172)
